Applygreasetotheexterioroftheswingarmbushings.
Applygreasetotherearshockabsorberbushing.
Inserttherearshockabsorberbushingandapplygreaseto
theexteriorexposededgeofthebushing.
Assemblyisthereverseofdisassembly.Torquetheshockabsorbernutandboltto25ft‐lbs.
Thereis
notorquespecificationfortheswingarmpivotaxlenuts.Tightentheswingarmpivotaxlenutsequally
suchthatthereisnoside‐to‐sideplayintheswingarmandtheswingarmpivotsupanddownwith
minimaldrag.

SwingarmandRearSuspensionTroubleshooting

Item Symptom Cause VehicleEffect MaintenanceAction
Swingarm Deformedswingarm Impact Pullstooneside Replaceswingarm
Fracturedswingarm Impact Pullstooneside Replaceswingarm
Stickyswingarmaction Inadequatelubrication,
overtightened
swingarmpivotaxle
nuts
Poorrearsuspension
action
Lubricateandadjust
asdirectedherein
Forks Springexcessivelysoft Forkhaspoorelastic
forceorisbroken
Poorcomfort Replaceforkspring
Leftandrightforksare
notatsamelevel
Forkdistorted Poorforkaction,
motorcyclepullsto
oneside
Adjustfork
