Completelyremovethecaliper’stwo5mmAllenpins,and
removethetwobrake pads.

Notethatunlikethefrontbrake,therearbrake’scalipersare
different.Theonewiththeextensiononitgoesonthe
insideoftherotor(thesideclosesttothespokes).

Whenthepadsare
wornoneithersidesuchthatthewearindicatorsarenolongervisible,replacethe
padswithnewpads.Wekeeptheseinstock,socallusat9094450900ifyouneedtoordera
pair.Notethatitisnormalforthefrontbrakepadstowear
muchmorequicklythantherearbrake
pads.

Assemblyisthereverseofdisassembly.Pushthecaliperpistonsallthewayintothecaliper.Installnew
rearbrakepads,installthetw o5mmAllenpins,placethecaliperovertherotor,andinstallthetwo
calipermountingbolts.The5mm
Allenpinsshouldbetorquedto3to5ft‐lbs.Thecalipermounting
boltsshouldbetorquedto15to18ft‐lbs.

FrontandRearBrakeRotorInspection

Boththefrontbrakeandrearbrakerotorsare4mmthick
whennew.Ifeitherrotorthicknessdropsbelow3mm,
the
rotorshouldbereplaced.

ThefrontandrearbrakerotorsareeachretainedbyAllenheadbolts thattakea6mmdrive.These
shouldbetorquedto22ft‐lbs.Takecarewhenremovingtheseforthefirsttime;theyareLoctitedin
placeatthefactoryandit
iseasytostriptheAllendrivesocket(werecommendheatingtheheadofthe
boltfirsttosoftentheadhesive).Wekeepreplacementrotorsinstock;ifyouneedanewrotorplease
callusat9094450900.
