28

Theleftsideoftherearaxle.

Theleftsidetakesa19mmwrench.
Therearaxleadjustornutsandlocknutsarelocatedbehind
theadjustorplateonbothsidesoftheswingarm.Theseare
13mmnuts.Loosenbothnutsonbothsidesofthe
swingarm.

Theintentisto
positionandaligntherearwheelsuchthatthechainhas3/5ofaninchslackatits
midpoint.Thisistheamountofslackthechainshouldhavewiththemotorcycleonthegroundand
therideronthebike.Ifthebikeisonaliftsuchthat
therearwheelisofftheground,youshould
increasetheamountofslackwhenyouadjustthechainsuchthatwhenyouareonthebike,theslackis 
3/5ofaninch.Iftherearwheelmustmoveforwardtoincreasechainslack,backoffontheadjustor
nuts
andlocknutsandmanuallypushtherearwheelforward.Iftherearwheelmustmoverearwardto
decreasechainslack,tightentheinnernutsasrequiredonbothsidesoftheswingarmtomovetheaxle
totherear.
Aftermovingtherearwheel,putascrewdriverbetweenthe
chain
andtherearwheelsprocket(asshownbelow)and
sharplyrotatetherearwheel.Thiswillremoveanykinksin
thechain.

