TT250Owner’s andServiceManual
www.CSCMotorcycles.com
34

Removethe1310mmboltssecuringtherightenginecover
totheengine.
Taptherightenginecoverlightlywithasoftmallettoloosen
it.
Removetherightenginecover.
Atthispoint,youwillseetheengineinternalsontherightsideoftheengine.Thesecomponentsare
labeled
hereforreferenceduringtheremainderofthistutorial.
