Thereisawasherunderneaththecastellatednut.This
washerislabeledtoshowwhichsideshouldfaceout.
Pulltheinnerportionofthecentrifugaloilcleaneroffofits
shaft.
Atthispoint(afterremovingtheinnerportionofthe
centrifugaloilcleaner),theclutchinnerbasketandclutch

componentscanberemoved.
Theclutchconsistsofsixfiberplatesandfivesteel
plates.Thefiberplatesaretheouterplatesonbothsidesof
theclutchassembly.Theplatesalternate(fiber,steel,fiber, 
steel,etc.).

CSCstockstheclutchplatesandtheclutchsprings.Please
callusat
9094450900ifyouneedthesecomponents.

