TheTT250usesaKeimaslidecarburetor.Itwillbemuch
easiertogainaccesstothecarburetorifthefueltankis
removed.Removingthefueltankinvolvesremovingtherear
bodypanelsandtheseat,detachingthetankbodypanels
fromthefra me(youdonotneedtoremove
thebodypanels
fromthetank),disconnectingthefuellinefromthe
carburetor,removingthefueltank,anddisconnectingthe
fueltankelectricalconnectiontothefuelgage.
LoosenthePhillipsheadscrewsecuringtheairboxinletto
thecarburetor.
Detachitfromthecarburetor.
Unscrewthecarburetorslideassembly
capandremovethe
carburetorslideassemblyfromthecarburetor.
Pulltheslideoutofthecarburetorbody.
