Chapter 6. Manage / Configure the Switch
107
Name: The name of the port.
Admin: It shows current port enable/disable status.
Auto: It shows current Auto enable/disable status of ports.
Speed/Duplex: It shows current working speed and duplex mode if ports are link up. Or the setting of speed/duplex
when auto is disable.
Flow Control: It shows current Flow Control function status of ports.
Power Saving: It shows current Power Saving enable/disable status of ports.
MDI/MDI-X: It shows current MDI/MDI-X setting of ports.
Link: It shows the link status of each port.
3). Max Packet Length
This switch supports Jumbo Frame function. And the maximum packet size could be up to 9600 byte/packet. You can
select the maximum packet size for each port here.
4). Mirror Port Configuration
This switch operates in store-and-forward algorithm so it is not possible to monitor network traffic from another
connection port. But the port mirror function can copy packets from some monitored port to another port for network
monitor.
