Curtis Instruments AC F4-A User Manual

4 — PROGRAMMABLE PARAMETERS
pg. 105
Return to TOC Curtis AC F4-A Motor Controller – August 2020
CONTROLLER SETUP — EXTERNAL SUPPLIES MENU
PARAMETER ALLOWABLE RANGE DEFAULT DESCRIPTION
5V Output Enable
Ext_5V_Output_Enable
0x36A8 0x00
On/Off
On/Off
On Enables the 5 V Power Supply Output.
12V Output Enable
Ext_12V_Output_Enable
0x36A7 0x00
On/Off
On/Off
Off Enables the 12 V Power Supply Output.
5V Measured
External_5V_Supply
0x36AA 0x00
0.00 – 100.00
0 – 10000
Read Only Voltage at +5 V output (pin 26).
5V Supplied Current
Ext_5V_Current
0x36AE 0x00
0 – 200 mA
0 – 200
Read Only Current (mA) at +5 V output (pin 26).
See the limit of the controller model.
12V Measured
External_12V_Supply
0x36AB 0x00
0.00 – 100.00
0 – 10000
Read Only Voltage at +12 V output (pin 25).
12V Supplied Current
Ext_12V_Current
0x36AF 0x00
0 – 200 mA
0 – 200
Read Only Current (mA) at +12 V output (pin 25).
See the limit of the controller model.
Total Supplied Current
Ext_Supply_Current_mA
0x36A9 0x00
0 – 200 mA
0 – 200
Read Only Total current from both 5 V and 12 V supplies.
Maximum is 200 mA.
5V Supply Min
Ext_5v_Supply_Min
0x36A4 0x00
0 – 200 mA 0 mA Sets the lower threshold of the current of the 5V external supply.
Current below this threshold will generate a fault that can be read
by VCL.
5V Supply Max
Ext_5v_Supply_Max
0x36A3 0x00
0 – 100 mA 100 mA Sets the upper threshold of the current of the 5V external supply.
Current above this threshold will generate a fault that can be read
by VCL.
12V Supply Min
Ext_12v_Supply_Min
0x36A6 0x00
0 – 200 mA 0 mA Sets the lower threshold of the current of the 12V external supply.
Current below this threshold will generate a fault that can be read
by VCL.
12V Supply Max
Ext_12v_Supply_Max
0x36A5 0x00
0 – 100 mA 100 mA Sets the upper threshold of the current of the 12V external supply.
Current above this threshold will generate a fault that can be read
by VCL.
CONTROLLER SETUP — OUTPUTS MENU, cont’d
PARAMETER ALLOWABLE RANGE DEFAULT DESCRIPTION
Driver 2–7
Driver X Checks Enable
Driver_X_Checks
On/Off
On/Off
Off See Driver 1
X = 2–7.
Driver_2_Checks : 0x341C 0x00
Driver_3_Checks : 0x341D 0x00
Driver_4_Checks : 0x341E 0x00
Driver_5_Checks : 0x341F 0x00
Driver_6_Checks : 0x3420 0x00
Driver_7_Checks : 0x3421 0x00
