Curtis Instruments AC F4-A User Manual

5 — SYSTEM MONITOR MENU
pg. 119
Return to TOC Curtis AC F4-A Motor Controller – August 2020
SYSTEM MONITOR / INPUTS MENU: SWITCH STATUS, cont’d
VARIABLE DISPLAY RANGE DESCRIPTION
Switch 21
Switch_21
0x3332 0x00
On/Off
On/Off
Switch 21 On or Off (pin 2).
Note: Typically not congured as a switch, but as Driver1.
Switch 22
Switch_22
0x3333 0x00
On/Off
On/Off
Switch 22 On or Off (pin 5).
Note: Typically not congured as a switch, but as Driver2.
Switch 23
Switch_23
0x3334 0x00
On/Off
On/Off
Switch 23 On or Off (pin 4).
Note: Typically not congured as a switch, but as Driver3.
Switch 24
Switch_24
0x3335 0x00
On/Off
On/Off
Switch 24 On or Off (pin 3).
Note: Typically not congured as a switch, but as Driver4.
Switch 25
Switch_25
0x3336 0x00
On/Off
On/Off
Switch 25 On or Off (pin 6).
Note: Typically not congured as a switch, but as Driver5.
Switch 26
Switch_26
0x3337 0x00
On/Off
On/Off
Switch 26 On or Off (pin 19).
Note: Typically not congured as a switch, but as Driver6.
Switch 27
Switch_27
0x3337 0x00
On/Off
On/Off
Switch 27 On or Off (pin 20).
Note: Typically not congured as a switch, but as Driver7.
Switch 31
Switch_31
0x333F 0x00
On/Off
On/Off
Switch 31 On or Off (pin 26).
Note: The +15V supply (pin 26), if not enabled, can be congured as a
switch input.
