Curtis Instruments AC F4-A User Manual

7 — DIAGNOSTICS AND TROUBLESHOOTING
pg. 173
Return to TOC Curtis AC F4-A Motor Controller – August 2020
Table 18 Fault Code Troubleshooting Chart, cont’d
FLASH
CODE
FAULT NAME
(Curtis Integrated Toolkit™)
POSSIBLE CAUSES SET/CLEAR CONDITIONS FAULT ACTIONS
5-11
0x5B
USER 18 FAULT
0x2751
See User 1 fault (above) Set: See User/OEM
documentation.
Clear: See User/OEM
documentation.
See User/OEM
documentation.
5-12
0x5C
USER 19 FAULT
0x2752
5-13
0x5D
USER 20 FAULT
0x2753
5-14
0x5E
USER 21 FAULT
0x2760
5-15
0x5F
USER 22 FAULT
0x2761
6-10
0x6A
USER 23 FAULT
0x2762
6-11
0x6B
USER 24 FAULT
0x2763
6-12
0x6C
USER 25 FAULT
0x2770
6-13
0x6D
USER 26 FAULT
0x2771
6-14
0x6E
USER 27 FAULT
0x2772
6-15
0x6F
USER 28 FAULT
0x2773
7-10
0x7A
USER 29 FAULT
0x2780
7-11
0x7B
USER 30 FAULT
0x2781
7-12
0x7C
USER 31 FAULT
0x2782
7-13
0x7D
USER 32 FAULT
0x2783
6-8
0x68
VCL Run Time Error
VCL_Run_Time_Error_Active
0x2820
Fault Type(s): 1
1. Runtime errors are dened using
the VCL Error Module and VCL
Error. See the System Information
le:
• Curtis Integrated Toolkit™ » VCL
Studio » Help
2. Using driver control commands in
VCL can lead to VCL runtime errors
if the VCL command and the driver
assignment do not match.
Set: VCL Run Time Error
detected
Clear: Edit the VCL application
software to x this error
condition; ash the new
compiled software and
matching parameter settings;
Reset Controller.
ShutdownAll:
ShutdownMotor
ShutdownMainContactor
ShutdownEMBrake
ShutdownThrottle
ShutdownInterlock
ShutdownDriver1
ShutdownDriver2
ShutdownDriver3
ShutdownDriver4
ShutdownDriver5
ShutdownDriver6
ShutdownDriver7
ShutdownPD
FullBrake
ShutdownPump
ShutdownCoilSupply
ShutdownVehicle
ShutdownLower
ShutdownLift
