Curtis PMC 1297 Manual
2
Preliminary on Verso page is set with right edge at 7 and 7/8,
and the top (as on the Recto page) at 1/4.
1 — OVERVIEW
Like all Curtis PMC motor controllers, the 1297 offers superior operator
control of motor speed. Features include:
150350 amp separately excited regenerative traction motor controller
Field current standard at 25 amps on 150 and 250 amp controllers,
and at 35 amps on 350 amp controllers
MultiMode feature allows two distinct user-selectable operation modes
200300 amp series pump motor controller, with choice of variable
PWM or ramped on/off
Proportional lowering valve is controlled by a variable-current driver,
for precise control during lowering
Lift and Lower operations start smoothly, because of hydraulic system
pre-load function
Programmability through the Curtis PMC 13XX programmer
Complete diagnostics through the 13XX programmer and through
the controllers built-in Status LED
Throttle inputs for single-ended or wigwag 5k pots or 05V throttles
(both standard full stroke and restricted range); one throttle for the
traction system and one for the hydraulic system
Active precharge of controller capacitor bank extends life of main
contactor tips
Three hourmeterstotal KSI-on hours, drive hours, pump hoursand
their associated maintenance timers are built into the controller, with
EEPROM storage (no battery)
BDI calculations performed within controller
Meets EEC fault detection requirements (standard M- PWM fault check)
Fault detection circuitry on throttle inputs can be used to inhibit
operation if traction or hydraulic throttle signal goes out of range
for any reason
Internal reverse polarity protection (no external diode required)
Continuous diagnostics during operation, with microprocessor
power-on self-test
All output drivers are short-circuit protected and provide built-in
coil spike protection
Positive battery connections for all inputs
