Write Bits
Writing bits allows you to:
• Modify the contents of the bits stored in the absolute address (R, L, M, K, or F).
• Change the bit state between On/Off.
• Change multiple consecutive bytes.
Query (Q) Frame
Response (R) Frame
Completion Code
Fixed
CRC
DA SA $82 $01 $00 L H
BASE BASE +0 BASE +1 BASE+N-3 CRC
To turn On the desired bit value from the base,
enter $FF. To change to Off, enter $00.
bsolute bit address (starting address)
DA SA $02 N L H Bit value Bit value .… Bit value L H
Base Base+0 Base+1 Base+N-3 CRC
