44 D50 PLC User's Manual
Timer/Counter (TC0-255)
The table below gives the alternate Word address for the timer/counter Set Value and Present Value
Ch SV PV Ch SV PV Ch SV PV
0 W2048 W2304 40 W2088 W2344 80 W2128 W2384
1 W2049 W2305 41 W2089 W2345 81 W2129 W2385
2 W2050 W2306 42 W2090 W2346 82 W2130 W2386
3 W2051 W2307 43 W2091 W2347 83 W2131 W2387
4 W2052 W2308 44 W2092 W2348 84 W2132 W2388
5 W2053 W2309 45 W2093 W2349 85 W2133 W2389
6 W2054 W2310 46 W2094 W2350 86 W2134 W2390
7 W2055 W2311 47 W2095 W2351 87 W2135 W2391
8 W2056 W2312 48 W2096 W2352 88 W2136 W2392
9 W2057 W2313 49 W2097 W2353 89 W2137 W2393
10 W2058 W2314 50 W2098 W2354 90 W2138 W2394
11 W2059 W2315 51 W2099 W2355 91 W2139 W2395
12 W2060 W2316 52 W2100 W2356 92 W2140 W2396
13 W2061 W2317 53 W2101 W2357 93 W2141 W2397
14 W2062 W2318 54 W2102 W2358 94 W2142 W2398
15 W2063 W2319 55 W2103 W2359 95 W2143 W2399
16 W2064 W2320 56 W2104 W2360 96 W2144 W2400
17 W2065 W2321 57 W2105 W2361 97 W2145 W2401
18 W2066 W2322 58 W2106 W2362 98 W2146 W2402
19 W2067 W2323 59 W2107 W2363 99 W2147 W2403
20 W2068 W2324 60 W2108 W2364 100 W2148 W2404
21 W2069 W2325 61 W2109 W2365 101 W2149 W2405
22 W2070 W2326 62 W2110 W2366 102 W2150 W2406
23 W2071 W2327 63 W2111 W2367 103 W2151 W2407
24 W2072 W2328 64 W2112 W2368 104 W2152 W2408
25 W2073 W2329 65 W2113 W2369 105 W2153 W2409
26 W2074 W2330 66 W2114 W2370 106 W2154 W2410
27 W2075 W2331 67 W2115 W2371 107 W2155 W2411
28 W2076 W2332 68 W2116 W2372 108 W2156 W2412
29 W2077 W2333 69 W2117 W2373 109 W2157 W2413
30 W2078 W2334 70 W2118 W2374 110 W2158 W2414
31 W2079 W2335 71 W2119 W2375 111 W2159 W2415
32 W2080 W2336 72 W2120 W2376 112 W2160 W2416
33 W2081 W2337 73 W2121 W2377 113 W2161 W2417
34 W2082 W2338 74 W2122 W2378 114 W2162 W2418
35 W2083 W2339 75 W2123 W2379 115 W2163 W2419
36 W2084 W2340 76 W2124 W2380 116 W2164 W2420
37 W2085 W2341 77 W2125 W2381 117 W2165 W2421
38 W2086 W2342 78 W2126 W2382 118 W2166 W2422
39 W2087 W2343 79 W2127 W2383 119 W2167 W2423
