6 D50 PLC User's Manual
D50 PLC System Components
RS232
RS 48 5
GPC5/WinGPC
Program Loader
Software
RS232/485
Adapter
D50CPM485
Programming Cable
D50CBL10
D50 Controller
Digital Expander
(up to 3)
Analog Expander
(up to 2)
Series D50
