Appendix C: D50PGM10 Pocket Editor 189
Function Keys
There are 8 function keys on the pocket editor, plus two functions that are accessed using the SHF key.
The 10 functions each have multiple uses, based on the mode of operation the pocket editor is being
used in.
Function Key Descriptions
Key Function Descriptions
DEL Delete a step of logic. To accept the Delete request, press the ENT key after the DEL key.
INS Insert a step of logic in front of the current step.
Clear the program.
Change the PLC mode between RUN/STOP.
ENT Enter a step of logic.
Switch between displaying instruction and step number.
Accept the requested function.
CLR Cancel key input.
Cancel the current display mode.
Release a forced output.
SHF Enable the shifted operation of each key.
SCH Search for an instruction, step address, or register.
PRE Return to the previously displayed step, or register.
NXT Advance to the next step or register.
