Cutler-Hammer D50 - Electrical and Input;Output Specifications

Chapter 3: Product Specification 13
Electrical Specifications
Power Supply Specifications
Internal Circuit Diagram
Wiring Diagram
Specifications
Voltage Input AC Models: 85-264VAC; DC Models: 20-28VDC
AC Frequency 47-63Hz
Current Consumption Max. 0.6A
Output Power 24VDC @ 700mA max.
Internal
Circuit
FUSE
AC
85-264V
FG
Programmable Controller D5 0
DC 24V
OUT
C0
0
1
1
2
2
3
3
4
4
5
5
6
7
C
CCC
IN IN
IN
OUT
OUT OUT
RUN
ERR
RUN
STOP
0123 4567
0123 45
Cutler-Hammer
OUTGND IN 100-240V
85-264VAC In
24VDC Out
