Appendix C: D50PGM10 Pocket Editor 209
Operating Procedure
Display
Key Sequence LED 5-Digit Display Mnemonic Instruction
STR R 3 INS STR R 3 STR R0.3
MCS INS MCS MCS
STR M 0 INS STR M 0 STR M0.0
OR M 1 INS OR M 1 OR M0.1
STR M 2 INS STR M 2 STR M0.2
OR M 3 INS OR M 3 OR M0.3
AND MCS INS AND MCS ANB
NOT INS NOT NOT
OUT M 4 INS OUT M 4 OUT M0.4
STR M 4 INS STR M 4 STR M0.4
AND M 1 0 0 INS AND M 100 AND M1.0
STR M 1 0 1 INS STR M 101 STR M1.1
AND M 1 0 2 INS AND M 102 AND M1.2
OR MCS INS OR MCS ORB
OUT R 1 5 0 2 INS OUT R 1502 OUT R15.2
STR F 1 5 INS STR F 15 STR F0.15
MCR INS MCR MCR
