Cutler-Hammer D50 - Page 85

72 D50 PLC User's Manual
Example
Program Expression Time Chart
U input (R0.0)
Down Input (R0.1)
Reset Input (TC15)
Present Value (PV64) 0 1 2 3 4 5 4 3 2 1 0 0 1 2 3 4 0
Output (TC64)
R000.0 UDC
U CH = 64
R000.1 SV = 5
S
TC15 R
TC64 M1.0
(OUT)
