ModEva Pac User Manual
April
2016
V2.3
8. Touch the angLe field, Bend column, and enter the measured angle (93.0 in this case).
The software automatically calculates the necessary correction (-0.436, which can
be seen in the y1, y2 fields, in the Bend column).
See also the Corrections section in the 2D Reference Manual.
9. Carry out a second test bend (on the same sequence, with a second test product). If
necessary, make a new correction.
Depending on the material, the machine adjustment and the exactness of the
data introduced, 2 or 3 corrections can be necessary for a bend. This can be
considered as being a normal situation.
10. Proceed in the same manner for all the bends by navigating through the bends by
means of the
and keys.
11. When all the bends of the product turn out as expected, go into automatic mode
and choose the work page you like:
• Bend Numerical (see page 9),
• Bend 2D Page (see page 22),
• Bend 3D (see page 9) for 3D software.
