20D-Link DCS-5220 User Manual
Section 3 - Configuration
Web-based Configuration Utility
To access the conguration utility, open a web-browser such as
Internet browser and enter the IP address of your Network Camera
(http://192.168.0.120)
Note: In the example, this address is 192.168.0.120. Your address may differ.
Type Admin in the user name eld and leave the password blank
by default.
Note: You may refer to page 64 to change the password for your
admin account.
This section will show you how to congure your new D-Link Network Camera using the Web-based Conguration
Utility.
Click OK

Other manuals for D-Link DCS-5220

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the D-Link DCS-5220 and is the answer not in the manual?

D-Link DCS-5220 Specifications

Operating Environment IconOperating Environment
operating temperature0˚ to 40˚C (32˚- 104˚F)
storage temperature-40˚ to 70˚C (-14˚ - 158˚F)
humidityMax. 95% RH
Power IconPower
external power supply12V DC 1.5A
power consumption4.8 Watts
Camera Specifications IconCamera Specifications
cmos sensor1/4”
minimum illumination0.5 Lux @ F2.0
viewing angle horizontal270º
viewing angle vertical90º
Video and Audio IconVideo and Audio
video resolution at 160x120Up to 30fps
video resolution at 176x144Up to 30fps
video resolution at 320x240Up to 30fps
video resolution at 640x480Up to 30fps
audio bitrate AAC16kbps~128kbps
audio bitrate GSM-AMR4.75kbps~12.2kbps
Weight and Dimensions IconWeight and Dimensions
width4.1”
height4.4”
depth4.3”
item weight0.7 lbs
packaging weight2.9 lbs
