Section 3 - Configuration
Application
A typical application is that when motion is detected, the DCS-5220 Network Camera sends images to a FTP server or
via e-mail as notications. For example, as seen in the illustration below, an event can be triggered by many sources,
such as motion detection or external digital input devices. When an event is triggered, you can specify what kind of
action will be performed. You can congure the Network Camera to send snapshots or videos to your email address
or FTP site.
To start plotting an event, it is suggested to congure server and media columns rst so that the Network Camera will
know what action shall be performed when a trigger is activated.
ex.
Motion detection,
Periodically, Digital input,
System reboot
Event Condition
ex.
Snapshot, Video Clips
ex.
Email, FTP
Media
(what to send)
Server
(where to send)
Action

D-Link DCS-5220 Specifications

Operating Environment

operating temperature	0˚ to 40˚C (32˚- 104˚F)
storage temperature	-40˚ to 70˚C (-14˚ - 158˚F)
humidity	Max. 95% RH

Power

external power supply	12V DC 1.5A
power consumption	4.8 Watts

Camera Specifications

cmos sensor	1/4”
minimum illumination	0.5 Lux @ F2.0
viewing angle horizontal	270º
viewing angle vertical	90º

Video and Audio

video resolution at 160x120	Up to 30fps
video resolution at 176x144	Up to 30fps
video resolution at 320x240	Up to 30fps
video resolution at 640x480	Up to 30fps
audio bitrate AAC	16kbps~128kbps
audio bitrate GSM-AMR	4.75kbps~12.2kbps

Weight and Dimensions

width	4.1”
height	4.4”
depth	4.3”
item weight	0.7 lbs
packaging weight	2.9 lbs
