D-Link DCS-5220 User Manual

23D-Link DCS-5220 User Manual
Section 3 - Configuration
Using 3GPP Mobile Phones
To view streaming media using mobile phones, make sure the Network Camera is setup on the Internet.
To utilize this feature, please check the Network Settings for your camera.
1. Most of the players on 3GPP mobile phones do not support RTSP authentication. Make sure the
authentication mode of RTSP streaming is set to Disable. For more information, see page 44.
2. The 3G network bandwidth is limited, therefore users cannot use large size videos. Please set the
video and audio streaming parameters as listed below. For more information, see Audio and Video
on page 51.
Video Mode MPEG-4
Frame size 176 x 144
Maximum frame rate 5 fps
Intra frame period 1S
Video quality (Constant bit rate) 40kbps
Audio type (GSM-AMR) 12.2kbps
3. Set the RTSP port to 554, since most ISPs and players do not support other port numbers.
4. Launch the players on 3GPP mobile phones, (ex. Real Player). Type the URL command in the
player.
URL Command = rtsp://<public ip address of your camera>:<rtsp port>/<access name for stream1/
stream2>

D-Link DCS-5220 Specifications

Operating Environment

operating temperature	0˚ to 40˚C (32˚- 104˚F)
storage temperature	-40˚ to 70˚C (-14˚ - 158˚F)
humidity	Max. 95% RH

Power

external power supply	12V DC 1.5A
power consumption	4.8 Watts

Camera Specifications

cmos sensor	1/4”
minimum illumination	0.5 Lux @ F2.0
viewing angle horizontal	270º
viewing angle vertical	90º

Video and Audio

video resolution at 160x120	Up to 30fps
video resolution at 176x144	Up to 30fps
video resolution at 320x240	Up to 30fps
video resolution at 640x480	Up to 30fps
audio bitrate AAC	16kbps~128kbps
audio bitrate GSM-AMR	4.75kbps~12.2kbps

Weight and Dimensions

width	4.1”
height	4.4”
depth	4.3”
item weight	0.7 lbs
packaging weight	2.9 lbs
