D-Link DCS-5220 User Manual

70D-Link DCS-5220 User Manual
Section 3 - Configuration
D-ViewCam Installation
D-ViewCam software is included for the administrator to manage up to 32 D-Link network cameras remotely. The
administrator can use the software to congure the advanced settings for the camera. D-ViewCam is a complete
management tool and includes all congurative settings.
Insert the CD into the CD-ROM drive. A menu screen will appear as shown below.
D-ViewCam provides English, Traditional Chinese, and Simplied
Chinese language versions. Select a language version and click OK to
continue.
Click OK
Click Multicamera management

D-Link DCS-5220 Specifications

Operating Environment

operating temperature	0˚ to 40˚C (32˚- 104˚F)
storage temperature	-40˚ to 70˚C (-14˚ - 158˚F)
humidity	Max. 95% RH

Power

external power supply	12V DC 1.5A
power consumption	4.8 Watts

Camera Specifications

cmos sensor	1/4”
minimum illumination	0.5 Lux @ F2.0
viewing angle horizontal	270º
viewing angle vertical	90º

Video and Audio

video resolution at 160x120	Up to 30fps
video resolution at 176x144	Up to 30fps
video resolution at 320x240	Up to 30fps
video resolution at 640x480	Up to 30fps
audio bitrate AAC	16kbps~128kbps
audio bitrate GSM-AMR	4.75kbps~12.2kbps

Weight and Dimensions

width	4.1”
height	4.4”
depth	4.3”
item weight	0.7 lbs
packaging weight	2.9 lbs
