D-Link DCS-5220 User Manual

24D-Link DCS-5220 User Manual
Section 3 - Configuration
Camera
Logout: Logout the camera server and close the browser.
Client Settings: Click this button to access the Client Settings.
Snapshot: Capture a still picture of a video.
This section shows your camera’s live video. You can congure the settings using the buttons listed below.
Disable Digital
Zoom:
Zoom Factors:
Enable/Disable the digital zoom feature. After selecting this
icon, a small pop-up window will appear (see below).
Select this to disable the digital zoom feature.
Adjust the threshold of the zoom factor. You can also adjust
and position the zoom area by dragging the box in the
window.
Click this icon to hide the window.

D-Link DCS-5220 Specifications

Operating Environment

operating temperature	0˚ to 40˚C (32˚- 104˚F)
storage temperature	-40˚ to 70˚C (-14˚ - 158˚F)
humidity	Max. 95% RH

Power

external power supply	12V DC 1.5A
power consumption	4.8 Watts

Camera Specifications

cmos sensor	1/4”
minimum illumination	0.5 Lux @ F2.0
viewing angle horizontal	270º
viewing angle vertical	90º

Video and Audio

video resolution at 160x120	Up to 30fps
video resolution at 176x144	Up to 30fps
video resolution at 320x240	Up to 30fps
video resolution at 640x480	Up to 30fps
audio bitrate AAC	16kbps~128kbps
audio bitrate GSM-AMR	4.75kbps~12.2kbps

Weight and Dimensions

width	4.1”
height	4.4”
depth	4.3”
item weight	0.7 lbs
packaging weight	2.9 lbs
