D-Link DCS-5220 User Manual

85D-Link DCS-5220 User Manual
Appendix D - Frequently Asked Questions
The following steps generally apply to any router that you have on your network. The D-Link DIR-655 is used as an
example to clarify the conguration process. Congure the initial settings of the DIR-655 by following the steps outlined
in the DIR-655 Quick Installation Guide.
3 Access the Router with Your Web Browser
If you have cable or DSL Internet service, you will most likely have a
dynamically assigned WAN IP Address. ‘Dynamic’ means that your router’s
WAN IP address can change from time to time depending on your ISP. A
dynamic WAN IP Address identies your router on the public network and
allows it to access the Internet. To nd out what your router’s WAN IP Address
is, go to the Status menu on your router and locate the WAN information for
your router (as shown on the next page). The WAN IP Address will be listed.
This will be the address that you will need to type in your Web browser to
view your camera over the Internet.
Router Set-Up and Installation
Your WAN IP Address will be listed on the router’s
Status > Device Info page.

D-Link DCS-5220 Specifications

Operating Environment

operating temperature	0˚ to 40˚C (32˚- 104˚F)
storage temperature	-40˚ to 70˚C (-14˚ - 158˚F)
humidity	Max. 95% RH

Power

external power supply	12V DC 1.5A
power consumption	4.8 Watts

Camera Specifications

cmos sensor	1/4”
minimum illumination	0.5 Lux @ F2.0
viewing angle horizontal	270º
viewing angle vertical	90º

Video and Audio

video resolution at 160x120	Up to 30fps
video resolution at 176x144	Up to 30fps
video resolution at 320x240	Up to 30fps
video resolution at 640x480	Up to 30fps
audio bitrate AAC	16kbps~128kbps
audio bitrate GSM-AMR	4.75kbps~12.2kbps

Weight and Dimensions

width	4.1”
height	4.4”
depth	4.3”
item weight	0.7 lbs
packaging weight	2.9 lbs
