D-Link DCS-5220 User Manual

7D-Link DCS-5220 User Manual
Section 1 - Product Overview
Hardware Overview
Antenna Connector
One antenna is included with the DCS-5220. It is fastened onto the antenna connector located on
the back panel, which is used to provide a connection with a wireless network.
Power LED
As soon as the power Adapter is connected to the camera, the red LED and the green LED light will both appear
steady on. As the camera is booting, a ashing red LED and steady green LED light will appear next.
The red LED will be turned off during self-test. Upon passing the self-test, a steady red LED and ashing
green LED light will appear, indicating a good connection to the Ethernet port.
Microphone
The DCS-5220 Network Camera has a built-in internal
microphone.

D-Link DCS-5220 Specifications

Operating Environment

operating temperature	0˚ to 40˚C (32˚- 104˚F)
storage temperature	-40˚ to 70˚C (-14˚ - 158˚F)
humidity	Max. 95% RH

Power

external power supply	12V DC 1.5A
power consumption	4.8 Watts

Camera Specifications

cmos sensor	1/4”
minimum illumination	0.5 Lux @ F2.0
viewing angle horizontal	270º
viewing angle vertical	90º

Video and Audio

video resolution at 160x120	Up to 30fps
video resolution at 176x144	Up to 30fps
video resolution at 320x240	Up to 30fps
video resolution at 640x480	Up to 30fps
audio bitrate AAC	16kbps~128kbps
audio bitrate GSM-AMR	4.75kbps~12.2kbps

Weight and Dimensions

width	4.1”
height	4.4”
depth	4.3”
item weight	0.7 lbs
packaging weight	2.9 lbs
