D-Link DCS-5220 User Manual

82D-Link DCS-5220 User Manual
Appendix D - Frequently Asked Questions
Run the DCC program from the CD included with the DCS-5220. Follow the steps in the Quick Installation Guide to
congure the DCS-5220. The camera will be assigned a local IP Address that allows it to be recognized by the router.
Write down this IP Address for future reference.
1 Assign a Local IP Address to Your Camera
After you have completed the setup of the DCS-5220 outlined in the Quick Installation Guide you will have an operating
camera that has an assigned IP Address. Because you are using a router to share the Internet with one or more PCs,
the IP Address assigned to the Network Camera will be a local IP Address. This allows viewing within your Local Area
Network (LAN) until the router is congured to allow remote viewing of the camera over the Internet.
This is the IP Address assigned to your camera. Write it down for later use. 172.17.5.108 is only an example. You will
probably have a different IP Address.

D-Link DCS-5220 Specifications

Operating Environment

operating temperature	0˚ to 40˚C (32˚- 104˚F)
storage temperature	-40˚ to 70˚C (-14˚ - 158˚F)
humidity	Max. 95% RH

Power

external power supply	12V DC 1.5A
power consumption	4.8 Watts

Camera Specifications

cmos sensor	1/4”
minimum illumination	0.5 Lux @ F2.0
viewing angle horizontal	270º
viewing angle vertical	90º

Video and Audio

video resolution at 160x120	Up to 30fps
video resolution at 176x144	Up to 30fps
video resolution at 320x240	Up to 30fps
video resolution at 640x480	Up to 30fps
audio bitrate AAC	16kbps~128kbps
audio bitrate GSM-AMR	4.75kbps~12.2kbps

Weight and Dimensions

width	4.1”
height	4.4”
depth	4.3”
item weight	0.7 lbs
packaging weight	2.9 lbs
