DIR-816L Wireless AC750 Dual Band Router & Access Point
with 3G/CDMA/LTE Support and USB Port
User Manual
Configuring Device (Router Mode)
Parameter Description
SIP
Select the checkbox to enable SIP. Such a setting allows using the
SIP ALG function. This function allows VoIP traffic to pass through
the NAT-enabled router.
10
RTSP
Select the checkbox to enable RTSP. Such a setting allows managing
media stream: fast forward streaming audio/video, pause and start it.
PPPoE pass through Select the checkbox to enable the PPPoE pass through function.
PPTP pass through
Select the checkbox to enable the PPTP pass through function.
L2TP pass through Select the checkbox to enable the L2TP pass through function.
After specifying the needed parameters, click the Apply button.
10 On the Net / WAN page, create a WAN connection, on the Advanced / Miscellaneous page, select the SIP
checkbox, connect the phone cable between a LAN port of the router and the IP phone. Specify SIP parameters on
the IP phone and configure it to obtain an IP address automatically (as DHCP client).
Page 180 of 304
