Configuring Device (Access Point Mode)
When the Open or Shared authentication type is selected, the following fields are available:
Parameter Description
Enable Encryption WEP
The checkbox activating WEP encryption. When the checkbox is
selected, the Default Key ID field, the Encryption Key WEP as
HEX checkbox, the WEP key length drop-down list, and four
Encryption Key WEP fields are displayed on the page. For the
Shared authentication type the checkbox is always selected.
Default Key ID
The number of the key (from first to fourth) which will be used for
WEP encryption.
Encryption Key WEP as
HEX
Select the checkbox to set a hexadecimal number as a key for
encryption.
WEP key length
The length of WEP encryption key.
Select the value 64bit to specify keys containing 5 ASCII symbols
or 10 HEX symbols.
Select the value 128bit to specify keys containing 13 ASCII
symbols or 26 HEX symbols.
Encryption Key WEP (1-
4)
Keys for WEP encryption. The router uses the key selected from the
Default Key ID drop-down list. It is required to specify all the
fields.
When the WPA-PSK, WPA2-PSK, or WPA-PSK/WPA2-PSK mixed authentication type is
selected, the following fields are available:
Parameter Description
Encryption Key PSK
A key for WPA encryption. The key can contain digits and/or Latin
characters.
WPA Encryption An encryption method: TKIP, AES, or TKIP+AES.
When you have configured the parameters, click the Apply button.
In addition, when the Enable client checkbox is selected, the list of available wireless networks is
displayed on the page.
To view the latest data on the available 2.4GHz band wireless networks, click the Search button in
the Wireless networks in 2.4 GHz range section.
To view the latest data on the available 5GHz band wireless networks, click the Search button in
the Wireless networks in 5 GHz range section.
To connect to a wireless network from the list, select the needed network. Upon that the relevant
values are automatically inserted in the SSID, BSSID, and Network Authentication fields.
For the Open authentication type with no encryption, click the Apply button.
