12D-Link DSL-245GE User Manual
Section 2 - Installation
Use the DSL-245GE as a router only. Plug one end of the supplied Ethernet cable into the WAN port on the back
of the router and the other end to your existing cable/UFB/NBN™ connection box or modem. Then power on the
connection box.
2-2
DSL/cable modem
PC
Connect the supplied power adapter to the router and a power outlet, and press the power button. The device LEDs
will light up. Wait approximately three minutes before proceeding to the next step.
Caution: Use only the included power adapter with this product.
3
DSL-245GE
WALL JACK
POWER OUTLET
PC
To Next Page
