DWR-921 4G LTE Router
User Manual
Configuring via Web-based Interface
If needed, you can add your own address resource records. To do this, click the ADD button ( )
in the Hosts section (available if in the Dynamic IP Addresses section the DHCP value is
selected from the Mode of IPv4 address assignment drop-down list).
Figure 101. Configuring the local interface. The IPv4 tab. The window for adding a DNS record.
In the Name field, specify the domain or domain name to which the specified IPv4 address will
correspond. In the IP address field, specify a host from the internal or external network. You can
choose a device connected to the router's LAN at the moment. To do this, select the relevant IPv4
address from the drop-down list (the field will be filled in automatically). To specify several IP
addresses, click the ADD button. Click the SAVE button.
To edit an existing record, in the Hosts section, select the relevant line in the table. In the opened
window, change the needed parameters and click the SAVE button.
To remove a record, in the Hosts section, select the checkbox located to the left of the relevant line
in the table and click the DELETE button ( ).
After completing the work with records, click the APPLY button.
Page 118 of 255
