D-Link DWR-921 User Manual

DWR-921 4G LTE Router
User Manual
Configuring via Web-based Interface
3
On the Advanced / Redirect page, you can enable notifications on the reason of the Internet
connection failure. Notifications will be displayed in the browser window when a user is attempting
to open a web site on the Internet.
Figure 147. The Advanced / Redirect page.
To configure notifications, click the ENABLE button. Then, in the Reasons for Redirect
section, move the needed switches to the right.
Parameter Description
Reasons for Redirect
Physical connection
error
Notifications in case of physical connection problems (the ISP's
cable is not connected, an additional device needed to access the
Internet is not connected).
No connection
Notifications in case of problems of the default WAN connection
(authorization error, the IPS's server does not respond, etc.).
The device is not
configured
Notifications in case when the device works with default settings.
When you have configured the parameters, click the APPLY button.
To disable notifications, click the DISABLE button.
Page 186 of 255

D-Link DWR-921 Specifications

General

VPN support	L2TP/PPTP/IPSEC
Ethernet LAN	Yes
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3u
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Wi-Fi band	No
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
WLAN data transfer rate (max)	150 Mbit/s
Ethernet LAN (RJ-45) ports	4
DHCP client	-
Antennas quantity	2
Security algorithms	128-bit WEP, 64-bit WEP, WPA, WPA2
Certification	CE, Wi-Fi
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Product color	Black, White
LED indicators	3G, LAN, Power, WAN, WLAN

Weight and Dimensions

Depth	111.5 mm
Width	190 mm
Height	23.5 mm
Weight	500 g
