DWR-921 4G LTE Router
User Manual
Configuring via Web-based Interface
!)&!
This configuration step is available for the Router and WISP Repeater modes.
!
You should configure your WAN connection in accordance with data provided by your
Internet service provider (ISP). Make sure that you have obtained all necessary information
prior to configuring your connection. Otherwise contact your ISP.
1. On the Internet connection type page, click the SCAN button (available for the Router
mode only) to automatically specify the connection type used by your ISP or manually
select the needed value from the Connection type list.
2. Specify the settings necessary for the connection of the selected type.
3. If a particular MAC address was registered by your ISP upon concluding the agreement,
from the MAC address assignment method drop-down list (available for the Router
mode only), select the Manual value and enter this address in the MAC address field.
Choose the Clone MAC address of your device value to place the MAC address of
your network interface card in the field, or leave the Default MAC address value to place
the router’s WAN interface MAC address in the field.
4. If the Internet access is provided via a VLAN channel, select the Use VLAN checkbox and
fill in the VLAN ID field (available for the Router mode only).
5. Click the NEXT button to continue or click the BACK button to return to the previous page.
Page 51 of 255
