D-Link DWR-921 User Manual

DWR-921 4G LTE Router
User Manual
Configuring via Web-based Interface
Using WAN Port as LAN Port
To configure the WAN port of the router to be used as a LAN port, follow the next steps:
1. On the Connections Setup / WAN page, remove the WAN connection assigned to the
network interface of the VLAN which includes the WAN port (see the WAN section, page
75).
2. Go to the Advanced / VLAN page and remove the VLAN (see the VLAN section, page
174).
3. On the Advanced / WAN Assignment page, deselect the WAN port and click the
APPLY button.
If you don't want to use the WAN port as a LAN port any longer, follow the next steps:
1. On the Advanced / WAN Assignment page, select the WAN port and click the APPLY
button.
2. Go to the Advanced / VLAN page and create a VLAN which will include the WAN port
(see the VLAN section, page 174).
!
To create a network interface to which a WAN connection can be assigned upon adding the
VLAN, the Create interface switch should be moved to the right.
3. Go to the Connections Setup / WAN page and create a WAN connection which will be
assigned to the network interface of the VLAN (see the WAN section, page 75).
Page 178 of 255

D-Link DWR-921 Specifications

General

VPN support	L2TP/PPTP/IPSEC
Ethernet LAN	Yes
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3u
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Wi-Fi band	No
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
WLAN data transfer rate (max)	150 Mbit/s
Ethernet LAN (RJ-45) ports	4
DHCP client	-
Antennas quantity	2
Security algorithms	128-bit WEP, 64-bit WEP, WPA, WPA2
Certification	CE, Wi-Fi
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Product color	Black, White
LED indicators	3G, LAN, Power, WAN, WLAN

Weight and Dimensions

Depth	111.5 mm
Width	190 mm
Height	23.5 mm
Weight	500 g
