DWR-921 4G LTE Router
User Manual
Configuring via Web-based Interface
(
When a new text message is received, the relevant notification will be displayed in the top right
corner of the page. Click the CHECK button. After clicking the button, the LTE Modem /
Modem 1 / SMS page opens.
On the LTE Modem / Modem 1 / SMS page, you can create and send a text message and also
view the history and status of sent and received messages stored in the memory of the SIM card.
Figure 135. The LTE Modem / Modem 1 / SMS page. The SMS tab.
To view all outgoing and incoming messages on the SMS tab, select the relevant value from the
Message filter drop-down list.
To view the latest data on sent and received messages, click the REFRESH button.
To create and send a text message, click the New message button ( ).
Figure 136. The window for creating a new text message.
In the Number field, enter the recipient's phone number. If you need to send the text message to
several recipients, click the ADD button, and in the line displayed, enter a phone number. Enter the
text of the message in the Message field and click the SEND button.
Page 170 of 255

Table of Contents

Other manuals for D-Link DWR-921

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the D-Link DWR-921 and is the answer not in the manual?

D-Link DWR-921 Specifications

General IconGeneral
VPN supportL2TP/PPTP/IPSEC
Ethernet LANYes
Cabling technology10/100Base-T(X)
Networking standardsIEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3u
Ethernet LAN data rates10, 100 Mbit/s
Ethernet LAN interface typeFast Ethernet
Wi-Fi bandNo
Wi-Fi standards802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standardWi-Fi 4 (802.11n)
WLAN data transfer rate (max)150 Mbit/s
Ethernet LAN (RJ-45) ports4
DHCP client-
Antennas quantity2
Security algorithms128-bit WEP, 64-bit WEP, WPA, WPA2
CertificationCE, Wi-Fi
Operating temperature (T-T)0 - 40 °C
Operating relative humidity (H-H)10 - 90 %
Product colorBlack, White
LED indicators3G, LAN, Power, WAN, WLAN
Weight and Dimensions IconWeight and Dimensions
Depth111.5 mm
Width190 mm
Height23.5 mm
Weight500 g
