D-Link DWR-921 User Manual

DWR-921 4G LTE Router
User Manual
Configuring via Web-based Interface
!
On the Wi-Fi / Client page, you can configure the router as a client to connect to a wireless access
point or to a WISP.
Figure 127. The page for configuring the client mode.
To configure the router as a client, move the Enable switch to the right. Upon that the following
fields are displayed on the page:
Parameter Description
Broadcast wireless
network 2.4 GHz
If the switch is moved to the left, devices cannot connect to the
router's WLAN. Upon that the router can connect to another access
point as a wireless client.
Connecting to network
A method for connecting to another access point.
In the Wireless Networks section, the list of available wireless networks is displayed. To view
the latest data on available wireless networks, click the UPDATE LIST button.
To connect to a wireless network from the list, select the needed network. Move the Network
options switch to the right to view more detailed information on the network to which the router
connects. If a password is required, enter it in the relevant field. Click the CONNECT button.
Page 158 of 255

D-Link DWR-921 Specifications

General

VPN support	L2TP/PPTP/IPSEC
Ethernet LAN	Yes
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3u
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Wi-Fi band	No
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
WLAN data transfer rate (max)	150 Mbit/s
Ethernet LAN (RJ-45) ports	4
DHCP client	-
Antennas quantity	2
Security algorithms	128-bit WEP, 64-bit WEP, WPA, WPA2
Certification	CE, Wi-Fi
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Product color	Black, White
LED indicators	3G, LAN, Power, WAN, WLAN

Weight and Dimensions

Depth	111.5 mm
Width	190 mm
Height	23.5 mm
Weight	500 g
