D-Link DWR-921 User Manual

DWR-921 4G LTE Router
User Manual
Overview
Specifications
*
Hardware
Processor
· MT7620N (600MHz)
RAM
· 64MB, DDR1 RAM
Flash
· 16MB, SPI
Interfaces · Slot for SIM card (mini-SIM)
· 10/100BASE-TX WAN port
· 4 10/100BASE-TX LAN ports
LEDs · SIGNAL STRENGTH
· SMS
· LAN
· POWER
· 2G/3G
· 4G
· WLAN
Buttons · POWER ON/OFF button to power on/power off
· WPS button to set up wireless connection
· RESET button to restore factory default settings
Antenna · Two detachable LTE/3G antennas (3dBi gain)
· Two internal Wi-Fi antennas (3dBi gain)
MIMO
· 2 x 2
Power connector
· Power input connector (DC)
Software
WAN connection types · Mobile Internet
· PPPoE
· IPv6 PPPoE
· PPPoE Dual Stack
· Static IPv4 / Dynamic IPv4
· Static IPv6 / Dynamic IPv6
· PPPoE + Static IP (PPPoE Dual Access)
· PPPoE + Dynamic IP (PPPoE Dual Access)
· PPTP/L2TP + Static IP
· PPTP/L2TP + Dynamic IP
· L2TP Dual Stack
· IPIP6 in DSLite mode
· 6in4
· 6to4
· 6rd
* The device features are subject to change without notice. For the latest versions of the firmware and relevant
documentation, visit www.dlink.ru.
Page 8 of 255

D-Link DWR-921 Specifications

General

VPN support	L2TP/PPTP/IPSEC
Ethernet LAN	Yes
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3u
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Wi-Fi band	No
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
WLAN data transfer rate (max)	150 Mbit/s
Ethernet LAN (RJ-45) ports	4
DHCP client	-
Antennas quantity	2
Security algorithms	128-bit WEP, 64-bit WEP, WPA, WPA2
Certification	CE, Wi-Fi
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Product color	Black, White
LED indicators	3G, LAN, Power, WAN, WLAN

Weight and Dimensions

Depth	111.5 mm
Width	190 mm
Height	23.5 mm
Weight	500 g
