DWR-921 4G LTE Router
User Manual
Installation and Connection
Connecting to Web-based Interface
When you have configured your computer, you can access the web-based interface and configure
needed parameters (create a WAN connection, change the parameters of the wireless network,
specify the settings of the firewall, etc.).
!
Clients connected to the router with default settings do not have access to the Internet. To
get started, please set your own password for access to the web-based interface and change
the WLAN name (SSID); then, if needed, configure other settings recommended by your
ISP.
Start a web browser (see the Before You Begin section, page 16). In the address bar of the web
browser, enter the domain name of the router (by default, dlinkrouter.local) with a dot at
the end and press the Enter key. Also you can enter the IP address of the device (by default,
192.168.0.1).
Figure 22. Connecting to the web-based interface of the DWR-921 device.
!
If the error “ The page cannot be displayed ” (or “ Unable to display the page ”/“ Could not
connect to remote server ”) occurs upon connecting to the web-based interface of the router,
make sure that you have properly connected the router to your computer.
If the device has not been configured previously or the default settings have been restored, after
access to the web-based interface the Initial Configuration Wizard opens (see the Initial
Configuration Wizard section, page 41).
Figure 23. The page for running the Initial Configuration Wizard.
Page 34 of 255
