DWR-921 4G LTE Router
User Manual
Configuring via Web-based Interface
"
On the System / Schedule page, you can enable/disable Wi-Fi connection and the Wi-Fi filter,
configure automatic reboot of the device on a schedule, and set a schedule for different rules and
settings of the firewall.
!
Before creating a schedule you need to configure automatic synchronization of the system
time with a time server on the Internet (see t he System Time section, page 240 ).
Figure 172. The System / Schedule page.
To configure automatic reboot of the device on a schedule, click the REBOOT ON SCHEDULE
button in the Auto Reboot section.
Figure 173. The window for configuring automatic reboot on a schedule.
Page 228 of 255

Table of Contents

Other manuals for D-Link DWR-921

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the D-Link DWR-921 and is the answer not in the manual?

D-Link DWR-921 Specifications

General IconGeneral
VPN supportL2TP/PPTP/IPSEC
Ethernet LANYes
Cabling technology10/100Base-T(X)
Networking standardsIEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3u
Ethernet LAN data rates10, 100 Mbit/s
Ethernet LAN interface typeFast Ethernet
Wi-Fi bandNo
Wi-Fi standards802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standardWi-Fi 4 (802.11n)
WLAN data transfer rate (max)150 Mbit/s
Ethernet LAN (RJ-45) ports4
DHCP client-
Antennas quantity2
Security algorithms128-bit WEP, 64-bit WEP, WPA, WPA2
CertificationCE, Wi-Fi
Operating temperature (T-T)0 - 40 °C
Operating relative humidity (H-H)10 - 90 %
Product colorBlack, White
LED indicators3G, LAN, Power, WAN, WLAN
Weight and Dimensions IconWeight and Dimensions
Depth111.5 mm
Width190 mm
Height23.5 mm
Weight500 g
