D-Link DWR-921 User Manual

DWR-921 4G LTE Router
User Manual
Overview
LED Mode Description
WLAN
Solid green
The router's WLAN is on.
Fast blinking green
Data transfer though Wi-Fi network.
Slow blinking green
Attempting to add a wireless device via the WPS
function.
No light
The router's WLAN is off.
The RESET and WPS buttons are located on the front panel of the router.
Button Description
RESET
A button to restore the factory default settings.
To restore the factory defaults, push the button (with the device
turned on), hold it for 10 seconds, and then release the button.
WPS
A button to set up a wireless connection (the WPS function).
To use the WPS function: with the device turned on, push the button,
and release. The WLAN LED should start blinking slowly.
Page 13 of 255

D-Link DWR-921 Specifications

General

VPN support	L2TP/PPTP/IPSEC
Ethernet LAN	Yes
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3u
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Wi-Fi band	No
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
WLAN data transfer rate (max)	150 Mbit/s
Ethernet LAN (RJ-45) ports	4
DHCP client	-
Antennas quantity	2
Security algorithms	128-bit WEP, 64-bit WEP, WPA, WPA2
Certification	CE, Wi-Fi
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Product color	Black, White
LED indicators	3G, LAN, Power, WAN, WLAN

Weight and Dimensions

Depth	111.5 mm
Width	190 mm
Height	23.5 mm
Weight	500 g
