DWR-921 4G LTE Router
User Manual
Configuring via Web-based Interface
In the opened window, you can specify the following parameters:
Parameter Description
Enable
Move the switch to the right to enable the rule.
Move the switch to the left to disable the rule.
Name
A name for the rule for easier identification. You can specify any
name.
Interface
From the drop-down list, select an interface (WAN connection)
through which remote access to the router will operate. Leave the
Automatic value to allow remote access to operate through all
created WAN connections.
IP version
An IP version to which the rule will be applied. Select the relevant
value from the drop-down list.
Open access from any
external host
Move the switch to the right to allow access to the router for any
host. Upon that the IP address and Mask fields are not displayed.
IP address
A host or a subnet to which the rule is applied. You can specify an
IPv4 or IPv6 address.
Mask
For the IPv4-based network only.
The mask of the subnet.
Public port
For the IPv4-based network only.
An external port of the router. You can specify only one port.
Protocol
The protocol available for remote management of the router.
After specifying the needed parameters, click the SAVE button.
To set a schedule for the remote access rule, click the Set schedule icon ( ) in the line
corresponding to this rule. In the opened window, from the Rule drop-down list, select the Create
rule value to create a new schedule (see the Schedule section, page 228) or select the Select an
existing one value to use the existing one. Existing schedules are displayed in the Rule name
drop-down list.
To enable the rule for remote access at the time specified in the schedule and disable it at the other
time, select the Enable rule value from the Action drop-down list and click the SAVE button.
To disable the rule for remote access at the time specified in the schedule and enable it at the other
time, select the Disable rule value from the Action drop-down list and click the SAVE button.
To edit a rule for remote access, left-click the relevant rule. In the opened window, change the
needed parameters and click the SAVE button.
To change or delete the schedule for a rule, click the Edit schedule icon ( ) in the line
corresponding to this rule. In the opened window, change the parameters and click the SAVE
button or click the DELETE FROM SCHEDULE button.
Page 217 of 255
