D-Link DWR-921 User Manual

DWR-921 4G LTE Router
User Manual
Configuring via Web-based Interface
In the opened window, specify the following parameters:
Control Description
Reset / WPS
Command
From the drop-down list, select a command.
Action
From the drop-down list, select an action for the command.
• Single click: One short press of the button lasting less than
one second.
• Double click: Two short presses of the button.
• Long press: Pressing of the button for several seconds.
When this value is selected, the Button press duration
section is displayed.
Button press duration
Specify a period of time (in seconds) within which you should hold
the button to perform the specified action. You can specify values
from 2 to 60.
Click the SAVE button.
To edit the parameters for a command, select the relevant line in the table. In the opened window,
change the needed parameters and click the SAVE button.
To remove a command, select the checkbox located to the left of the relevant line in the table and
click the DELETE button ( ).
After specifying the needed parameters, click the APPLY button.
Page 223 of 255

D-Link DWR-921 Specifications

General

VPN support	L2TP/PPTP/IPSEC
Ethernet LAN	Yes
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3u
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Wi-Fi band	No
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
WLAN data transfer rate (max)	150 Mbit/s
Ethernet LAN (RJ-45) ports	4
DHCP client	-
Antennas quantity	2
Security algorithms	128-bit WEP, 64-bit WEP, WPA, WPA2
Certification	CE, Wi-Fi
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Product color	Black, White
LED indicators	3G, LAN, Power, WAN, WLAN

Weight and Dimensions

Depth	111.5 mm
Width	190 mm
Height	23.5 mm
Weight	500 g
