DXS-3350SR Gigabit Layer 3 Switch
Web-based User Interface
The user interface provides access to various Switch configuration and management screens, allows you to view
performance statistics, and permits you to graphically monitor the system status.
Areas of the User Interface
The figure below shows the user interface. The user interface is divided into 3 distinct areas as described in the table.
Area 2
Area 1
Area 3
Figure 5- 3. Main Web-Manager Screen
