xStack
®
DES-3200 Series Layer 2 Managed Fast Ethernet Switch CLI Reference Guide
165
Example
To transmit an LTM:
DES-3200-28P:admin#cfm linktrace 00-01-02-03-04-05 mepname mep1
Command: cfm linktrace 00-01-02-03-04-05 mepname mep1
Transaction ID: 26
Success.
DES-3200-28P:admin#
16-19 show cfm linktrace
Description
This command is used to show the link trace responses. The maximum link trace responses a
device can hold is 128.
Format
show cfm linktrace [mepname <string 32> | mepid <int 1-8191> md [<string 22> | md_index
<uint 1-4294967295>] ma [<string 22> | ma_index <uint 1-4294967295>]] {trans_id <uint>}
Parameters
mepname - Specify the MEP name used.
<string 32> - Enter the MEP name used here. This name can be up to 32 characters long.
mepid - Specify the MEP ID used.
<int 1-8191> - Enter the MEP ID used here. This value must be between 1 and 8191.
md - Specify the maintenance domain name.
<string 22> - Enter the maintenance domain name her. This name can be up to 22
characters long.
md_index - Specify the maintenance domain index.
<uint 1-4294967295> - Enter the maintenance domain index value here. This value
must between 1 and 4294967295.
ma - Specify the maintenance association name.
<string 22> - Enter the maintenance association name her. This name can be up to 22
characters long.
ma_index - Specify the maintenance association index.
<uint 1-4294967295> - Enter the maintenance association index value here. This value
must between 1 and 4294967295.
trans_id - (Optional) Specify the identifier of the transaction displayed.
<uint> - Enter the transaction ID used here.
Restrictions
None.
Example
To show the link trace reply when the "all MPs reply LTRs" function is enabled:
