xStack
®
DES-3200 Series Layer 2 Managed Fast Ethernet Switch CLI Reference Guide
503
57-13 config dscp trust
Description
This command is used to configure the state of DSCP trust per port. When DSCP is not trusted,
802.1p is trusted.
Format
config dscp trust [<portlist> | all] state [enable | disable]
Parameters
<portlist> - Enter the list of port used for this configuration.
all - Specify that the command apply to all ports on the Switch.
state - Enable or disable to trust DSCP. By default, DSCP trust is disabled.
enable - Specify that the DSCP trust state will be enabled.
disable - Specify that the DSCP trust state will be disabled.
Restrictions
Only Administrator, Operator and Power-User level users can issue this command.
Example
Enable DSCP trust on ports 1-8.
DES-3200-28P:admin#config dscp trust 1-8 state enable
Command: config dscp trust 1-8 state enable
Success.
DES-3200-28P:admin#
57-14 config 802.1p map
Description
This command is used to configure the mapping of 802.1p to the packet’s initial color. The
mapping of 802.1p to a color is used to determine the initial color of the packet when the policing
function of the packet is color aware and the packet is 1p-trusted.
Format
config 802.1p map {[<portlist> | all]} 1p_color <priority_list> to [green | red | yellow]
Parameters
<portlist> - (Optional) Enter the list of port used for this configuration.
all - (Optional) Specify that the command apply to all ports on the Switch.
1p_color - The list of source priority for imcoming packets.
<priority_list> - Specify the list of source priority for imcoming packets.
to - The mapped color for a packet.
