8ñ20
1. Open the engine hood an
d
support.
2. Rotate the front turn signa
counterclockwise and pull
lamp housing.
3. Depress the bulb an
counterclockwise to remov
bulb holder.
4. Insert the new bulb into t
depressing it and rotatin
g
5. Install the holder into the la
by rotating it clockwise.
FRONT TURN SIGNAL
1. Open the engine hood and engage the
support.
2. Rotate the plastic cap counterclockwise
and remove.
3. Disconnect the wiring harness
connector from rear of the bulb.
4. Pull out the bulb holder located next to
the head lamp bulb.
5. Remove the bulb by pulling straight out
of the bulb holder.
6. Replace the bulb with a new one.
7. Install in the reverse order of removel.
POSITION LAMP
3. Disconnect the wiring harness
connector from rear of the bulb.
4. Release the bulb retaining spring and
remove the bulb.
LOW BEAM
HEADLAMP HIGH AND
1. Open the engine hood and engage the
support.
2. Rotate the plastic cap counterclockwise
and remove.
5. Replace the bulb with a new one.
6. Install in the reverse order of removal.
7. Rotate the plastic cap clockwise.
bulb retaining spring
