Daewoo Cielo - Tail, Brake, Rear Turn Signal, Reverse and Rear Fog Lamps

8ñ22
LICENCE PLATE LA
1. Unscrew the two bolts
licence plate lamp housing
the lamp housing.
2. Remove the bulb holder f
r
housing by rotating it coun
3. Pull out the bulb from the
4. Insert a new bulb into the
5. Install the bulb holder in
housing by rotating it cloc
6. Screw the two bolts.
Outside
Turn signal
lamp
Brake/tail
lamp
Inside
Reverse
lamp
Fog lamp
Center
ó
Tail lamp
Location
Upper
Lower
SIGNAL, REVERSE AND
TAIL, BRAKE, REAR TURN
(Notch back)
1. Open the trank lid and disconnect the
protective cover.
2. Press the two locks upwards and
remove the cover.
3. Depress the bulb and rotate it
counterclockwise to remove it from the
bulb holder.
4. Replace the bulb with a new bulb.
5. Install in the reverse order of removal.
6. Bulb sequence.
REAR FOG LAMPS*
(Hatch back)
1. Open the trank lid and remove the
protective cover.
2. Disconnect the wiring harness.
3. Unscrew the two fixing nut inside and
the two fixing bolts outside.
4. Remove the lamp housing.
5. Rotate the bulb holder
counterclockwise and remove the bulb
holder from the lamp housing.
6. Depress the bulb and rotate it
counterclockwise to remove it from the
bulb holder.
7. Replace the bulb with a new one.
8. Install in the reverse order of removal.
9. Bulb sequence.
LH
Brake/tail
lamp
Turn signal
lamp
Fog lamp
or Reverse
lamp
RH
<
<
Reverse lamp
Location
TOP
CENTRE
BOTTOM
cover
fixing
nut
fixing bolt
