1. Open the engine hood and engage the
support.
2. Rotate the front turn signal bulb holder
counterclockwise and pull out from the
lamp housing.
3. Depress the bulb and rotate it
counterclockwise to remove it from the
bulb holder.
4. Insert the new bulb into the holder by
depressing it and rotating clockwise.
5. Install the holder into the lamp housing
by rotating it clockwise.
FRONT TURN SIGNAL LAMP
1. Rotate the plastic cap counterclockwise
and remove.
2. Release the bulb retaining spring and
remove the bulb.
3. Disconnect the wiring harness
connector.
4. Replace the bulb with a new one.
5. Install in the reverse order of removal.
FRONT FOG LAMP
bulb retaining spring
bulb retaining spring
connector
SIDE TURN SIGNAL LAMP
1. Remove the side turn signal lamp
assembly with pulling it rearward.
2. Rotate the bulb holder
counterclockwise and remove it from
the lamp housing.
3. Remove the bulb by pulling straight out
of the holder.
4. Replace the bulb with a new one.
5. Install in the reverse order of removal.
holder
bulb
cover
