8ñ9
CLUTCH FLUID
This fluid level should be between MIN and
MAX marks on the side of the reservoir.
If the fluid level is low, replenish it with the
recommended clutch fluid.
Low fluid level can indicate a leak in the
clutch system.
Have this system checked at your nearest
Daewoo dealer.
On a cold transmission, check is performed
using the side of the disptick marked "+20∞C,
while for a transmission at operating
temperature the side marked "+94∞C"
should be used.
Normal operating temperature is only
reached after motorway driving over a
distance of at least 15 to 20km or similar.
Add fluid through pipe only if the fluid
level has reached the "MIN" mark. Do not
go above the "MAX" mark. Extreme
cleanliness should be exercised during
checking and filling since dirty particles
entering the automatic transmission could
cause severe malfunctions.
Use only special fluid as given in the
lubricant chart.
3-SPEED AUTOMATIC
TRANSMISSION FLUID LEVEL
*
dipstick
pipe
MIN MAX +20∞C
+94∞C MIN MAX
To ensure proper functioning, efficiency
and durability of the automatic transmission,
it is of the utmost importance that the fluid
is always kept at the proper level.
The level must therefore be checked at the
intervals specified in the manual. The
dipstick bears the markings "MIN"(top-up)
and "MAX"(full).
The level must be checked with the engine
running and the selector lever in position
"P". with the vehicle on a level. To check
the level, pull out the oil dipstick, whip it
clean, reinsert it as far as it will go, and
then remove it.
Service interval Capacity
Change every 80,000km
or 4 yeasrs
(Fluid filter should be
replaced at the same time
with auto T/M fluid)
5.5~6L
