Daewoo Cielo - Licence Plate Lamp; Trunk Lamp

8ñ23
The wiring harness polarity + , ñ is marked
on the trunk lamp as below.
Pay attention to polarity when replacing the
trunk lamp.
TRUNK LAMP
Sectional area of
wiring harness
Color of
wiring
harness
Polarity
+ red 0.5mm
2
ñ grey 0.5mm
2
ROOM LAMPLICENCE PLATE LAMP
1. Unscrew the two bolts fixing the
licence plate lamp housing and remove
the lamp housing.
2. Remove the bulb holder from the lamp
housing by rotating it counterclockwise.
3. Pull out the bulb from the bulb holder.
4. Insert a new bulb into the holder.
5. Install the bulb holder into the lamp
housing by rotating it clockwise.
6. Screw the two bolts.
1. Prise the lamp out of recess, using a
screwdriver. Pry the room lamp lever
lens out of housing.
Before removing the room lamp, close
the front doors so that the lamp is not
live.
Be careful not to damage headlining.
2. Press bulb slightly towards spring clip
and remove.
3. Insert the new bulb.
4. Install in the reverse order of removal.
